VA Motion Controller Programming Manual
88
panel function introduction
cold start : indicates that the
PLC
starts executing the program from the initial state,
anDAll variables are defined initial values at the start time;
Warm start : Indicates that the hold type variable in the program maintains the state at the
last stop, and the other variables are the initial state.
Tip: Click the“Stop” button in the “Run” state to pause the operation of the PLC . All
the variables in the program will remain at the moment before the stop. At this time, the “warm
start” button is available. Click this button to continue the program. run.
: It is used to choose whether to save the program downloaded by the user (after
the
VA
motion controller is powered off). Before the user program is installed, you need to click
the “More” pop-up window to check the box as “Guided Project Permanent Station”. Leave"
and then click "Close" as shown in the figure (Note
:
If unchecked, the
PLC
will not be able to run
the last downloaded program after power-on, that is, the motion controller does not save the last
downloading program. Need to reinstall the program)
Info:It is used to view the
PLC
running status, the bytes occupied by the program memory,
the current scanning period setting, etc.; as shown
