VA Motion Controller Programming Manual

293

NS_MC_CamSet

Up to 1 module per axis for the entire project

NS_MC_CamWritePoint

Up to 1 module per axis for the entire project

NS_MC_CamWriteTappetValue

Up to 1 module per axis for the entire project

MC_ReadActualPosition

Any number

MC_ReadActualVelocity

Any number

MC_ReadMotionState

Any number

MC_ReadStatus

Any number

NS_MC_ReadParameter

Any number
