Vector VEC-VA Series User Manual

VA Motion Controller Programming Manual
508
Enable
(Execute bit)
When Enable by
FALSE Changes toTRUE
When the instruction is
executed.
BOOL
TRUE or FALSE
-
DI_Start_Valid
(External DI start
significant bit)
When the DI_Start_Valid
When becomes FALSE
TRUE, it allows you to
specify the external DI
active, high-speed counter
starts (DI has been
specified, be described in
detail down)
BOOL
TRUE or FALSE
-
Start
(Start bit)
When Start is TRUE,
start high-speed counter
BOOL
TRUE or FALSE
-
DI_Rest_Valid
_Level
(External
active-high bit is
cleared DI)
When DI_Reset_Valid_
Level is TRUE, DI is
cleared to clear high
BOOL
TRUE or FALSE
-
DI_Rest_Valid
_DEdge
(External DI
cleared falling
Significant bit)
When DI_Reset_Valid_
Dedge is TRUE, DI cleared
the falling edge clear
BOOL
TRUE or FALSE
-
DI_Rest_Valid
_UEdge
(Rising
external DI
cleared
Significant bit)
When DI_Reset_Valid_
Uedge is TRUE, DI cleared
to rising cleared
BOOL
TRUE or FALSE
-
DI_Reset_No
(External
input DI cleared
number)
Specifies the external
clear signal terminal, the
input value of 0 to 7
corresponding to the input
point I0 ~ I7,8 ~ 15
corresponding to the input
point I10 ~ I17
WORD
TRUE or FALSE
-
DI_Rest_Len_
Valid
(External DI
clearing interval
significant bit)
When DI_Rest_Len_Valid
When TRUE, DI clear
signal only effective in
clearing the zone
BOOL
TRUE or FALSE
-
DI_Reset_Len
Setting a valid range
WORD
-
