Virtex-6 FPGA GTX Transceivers User Guide www.xilinx.com 259
UG366 (v2.5) January 17, 2011
RX Gearbox
The state machine works by keeping track of valid and invalid synchronization headers.
Upon reset, block lock is deasserted, and the state is LOCK_INIT. The next state is
RESET_CNT where all counters are zeroed out. The synchronization header is analyzed in
the TEST_SH state. If the header is valid, sh_cnt is incremented in the VALID_SH state,
otherwise sh_count and sh_invalid_count are incremented in the INVALID_SH state.
X-Ref Target - Figure 4-47
Figure 4-47: Block Synchronization State Machine
LOCK_INIT
block_lock <= false
test_sh <= false
RESET_CNT
sh_cnt <= 0
sh_invalid_cnt <= 0
slip_done <= false
TEST_SH
test_sh <= false
VALID_SH
sh_cnt <= sh_cnt + 1
64_GOOD
block_lock <= true
SLIP
block_lock <= false
SLIP <= true
INVALID_SH
sh_cnt <= sh_cnt + 1
sh_invalid_cnt <= sh_invalid_cnt + 1
sh_cnt = 64 AND
sh_invalid_cnt = 0
sh_cnt = 64 AND
sh_invalid_cnt > 0
sh_cnt = 64 AND
sh_invalid_cnt < 16 AND
block_lock = true
sh_invalid_cnt = 16 OR
block_lock = false
slip_done = true
sh_valid = 0
Unconditional Transition
sh_valid = 1
test_sh = true AND
sh_cnt < 64
test_sh = 1
Unconditional Transition
test_sh = true AND
sh_cnt < 64 AND
sh_invalid_cnt < 16 AND
block_lock = true
UG366_c4_44_051509
