Virtex-6 FPGA GTX Transceivers User Guide www.xilinx.com 47

UG366 (v2.5) January 17, 2011

Implementation

FF1156 Package Placement Diagrams

Figure 1-10 through Figure 1-14 show the placement diagrams for the FF1156 package.

X-Ref Target - Figure 1-10

Figure 1-10: Placement Diagram for the FF1156 Package (1 of 5)

LX130T: GTXE1_X0Y19

LX195T: GTXE1_X0Y19

LX240T: GTXE1_X0Y19

LX365T: GTXE1_X0Y19

SX315T: GTXE1_X0Y19

SX475T: GTXE1_X0Y27

LX130T: GTXE1_X0Y18

LX195T: GTXE1_X0Y18

LX240T: GTXE1_X0Y18

LX365T: GTXE1_X0Y18

SX315T: GTXE1_X0Y18

SX475T: GTXE1_X0Y26

QUAD_116

LX130T: GTXE1_X0Y17

LX195T: GTXE1_X0Y17

LX240T: GTXE1_X0Y17

LX365T: GTXE1_X0Y17

SX315T: GTXE1_X0Y17

SX475T: GTXE1_X0Y25

LX130T: GTXE1_X0Y16

LX195T: GTXE1_X0Y16

LX240T: GTXE1_X0Y16

LX365T: GTXE1_X0Y16

SX315T: GTXE1_X0Y16

SX475T: GTXE1_X0Y24

MGTRXP3_116

MGTRXN3_116

MGTTXP3_116

MGTTXN3_116

MGTRXP2_116

MGTRXN2_116

MGTTXP2_116

MGTTXN2_116

MGTREFCLK1P_116

MGTREFCLK1N_116

MGTREFCLK0P_116

MGTREFCLK0N_116

MGTRXP1_116

MGTRXN1_116

MGTTXP1_116

MGTTXN1_116

MGTRXP0_116

MGTRXN0_116

MGTTXP0_116

MGTTXN0_116

UG366_c1_10_051509
