Virtex-6 FPGA GTX Transceivers User Guide www.xilinx.com 203
UG366 (v2.5) January 17, 2011
RX Equalizer
Table 4-20 provides DFETAP1 and RXEQMIX settings for 6.25 Gb/s operation for
backplane applications.
Use Mode – Auto-To-Fix
This is an advance feature.
Use Mode – Auto
This is an advance feature.
60 [1524.0]
(4)
20.4 10 5
Notes:
1. GTX TXDIFFCTRL = 4'b1010, TXPOSTEMPHASIS = 5'b00000, and
TXPREEMPHASIS = 4'b0000.
2. Nominal 24 inches [609.6 mm] trace length = 6 inches [152.4 mm] backplane + 2 HmZD or eHSD
connectors (trace length neglected) + 18 inches [457.2 mm] on line cards.
3. Nominal 40 inches [1016.0 mm] trace length = 20 inches [508 mm] backplane + 2 HmZD or eHSD
connectors (trace length neglected) + 20 inches [508 mm] on line cards.
4. Nominal 60 inches [1524.0 mm] trace length = 40 inches [1016 mm] backplane + 2 HmZD or eHSD
connectors (trace length neglected) + 20 inches [508 mm] on line cards.
Table 4-20: DFETAP1 and RXEQMIX at 6.25 Gb/s for Backplane Applications
Nominal Trace
Length on FR4
Substrate
(inches [mm])
Loss (dB) @
3.125 GHz
TAP1
RXEQMIX = 000 RXEQMIX = 010 RXEQMIX = 110
24 [609.6]
(2)
15.8 10 0
40 [1016.0]
(3)
19.9 15 5
60 [1524.0]
(4)
25.8 15 10
Notes:
1. GTX TXDIFFCTRL = 4'b1010, TXPOSTEMPHASIS = 5'b00000, and
TXPREEMPHASIS = 4'b0000.
2. Nominal 24 inches [609.6 mm] trace length = 6 inches [152.4 mm] backplane + 2 HmZD or eHSD
connectors (trace length neglected) + 18 inches [457.2 mm] on line cards.
3. Nominal 40 inches [1016.0 mm] trace length = 20 inches [508 mm] backplane + 2 HmZD or eHSD
connectors (trace length neglected) + 20 inches [508 mm] on line cards.
4. Nominal 60 inches [1524.0 mm] trace length = 40 inches [1016 mm] backplane + 2 HmZD or eHSD
connectors (trace length neglected) + 20 inches [508 mm] on line cards.
Table 4-19: DFETAP1 and RXEQMIX at 5 Gb/s for Backplane Applications (Cont’d)
Nominal Trace
Length on FR4
Substrate
(inches [mm])
Loss (dB) @
2.5 GHz
TAP1
RXEQMIX = 000 RXEQMIX = 010 RXEQMIX = 110
