Virtex-6 FPGA GTX Transceivers User Guide www.xilinx.com 19

UG366 (v2.5) January 17, 2011

Chapter 1

Transceiver and Tool Overview

Overview

The Virtex®-6 FPGA GTX transceiver is a power-efficient transceiver. The GTX transceiver

is highly configurable and tightly integrated with the programmable logic resources of the

FPGA. It provides the following features to support a wide variety of applications:

• Current Mode Logic (CML) serial drivers/buffers with configurable termination,

voltage swing

• Programmable TX pre-emphasis/post-emphasis, RX equalization, and linear and

decision feedback equalization (DFE) for optimized signal integrity.

• Line rates from 600 Mb/s to 6.6 Gb/s, with optional 5X digital oversampling required

for rates between 480 Mb/s and 600 Mb/s.

• Optional built-in PCS features, such as 8B/10B encoding, comma alignment, channel

bonding, and clock correction.

• Fixed latency modes for minimized, deterministic datapath latency.

• Beacon signaling for PCI Express® designs and Out-of-Band signaling including

COM signal support for SATA designs.

• RX/TX Gearbox provides header insertion and extraction support for 64B/66B and

64B/67B (Interlaken) protocols.

• Receiver eye scan

Horizontal eye scan in the time domain for testing purposes

The first-time user is recommended to read High-Speed Serial I/O Made Simple [Ref 1], which

discusses high-speed serial transceiver technology and its applications. The

CORE Generator™ tool includes a Wizard to automatically configure GTX transceivers to

support configurations for different protocols or perform custom configuration (see

Virtex-6 FPGA GTX Transceiver Wizard). The GTX transceiver offers a data rate range and

features that allow physical layer support for various protocols.

Figure 1-1 illustrates a block view of the Virtex-6 FPGA GTX transceiver.
