18-6
IM 701210-06E
18.2 Messages and Corrective Actions
Code Message and Corrective Action Section
836 Cannot change settings during Action On Trigger. Stop the Action On Trigger. 6.18
837 Cannot set the channels which do not have modules installed. –
838 Cannot set the channels which do not have the strain module installed. –
839 Cannot Set or Execute. 11.10
840 If the trigger mode is set to Single, Single (N), or LOG, the acquisition mode cannot be set to Average. 6.1, 7.3
843 If the acquisition mode is Average, the trigger mode cannot be set to Single, Single (N), or Log. 6.1, 7.3
844 It can’t be set at the time of the roll mode. 5.2
845 The trigger mode cannot be set to Single(N) during the roll mode. 5.2, 6.1
850 The acquisition mode cannot be set in the current record length. 7.2
851 Computation cannot be carried out at the current record length. 7.2
853 Cannot be configured or executed during the search operation. 11.2 to 11.4
855 Cannot be configured or executed during the history search operation. 11.2, 11.3
856 The record cannot be selected. 11.1 to 11.3
857 History record does not exist. 11.1 to 11.3
858 Cannot be configured or executed while computation is in progress. 11.1 to 11.3
Aborted when history display mode is set to One.
859 It can’t be set up or be carried out in the Preview mode. 12.2
Choose Quit, and cancel the Preview mode.
860 Cannot be configured or executed while updating the history all display. 11.1 to 11.3
Aborted when history display mode is set to One.
861 This format cannot output with color. 12.3, 12.4
862 Zones cannot be edited in the following cases: When the main window is not displayed. 11.9
When the relevant waveform is not displayed.
863 The zone waveform does not exist. 11.9
865 Zones determination is not possible in the following cases: 11.9
When the main window is not displayed. When the relevant waveform is not displayed.
When the zone waveform does not exist.
867 Conflict in the waveform display plane. 11.9
Set the Mode to something other than Zone using the GO/NO-GO menu.
868 Processing statistics. 11.7
To perform other operations, abort the statistical processing.
869 The channel which couldn’t be set up was specified. Chapter 11,
13.7
870 Cannot be set when the acquisition mode is set to average. 7.3
871 Cannot be set in the dual capture mode. 7.6
872 Cannot be set during realtime recording. 7.7
873 It is an unacceptable parameter to set up to the present module. Chapter 5
874 It can't be set up during the dual capture practice. 7.6
875 Cannot be set to a range of 20 sec/div to 3 day/div during roll display. 5.2
876 Because a record length is too long, it can’t be set up by the present number of indication channels. 7.2
877 Cannot be set because there are too many display channels at the current record length. 7.2
Shorten the record length.
878 Zooming is not available when the number of displayed points of the FFT waveform is less than 50 10.3
in the Zoom window. Aborted when history display mode is set to One.
879 It is the dual capture record length which can’t be set up. 7.6
880 Cannot change this setting during realtime recording. 7.7
881 The time base cannot be set to external clock when the acquisition mode is set to envelope or 7.3, 5.14
box average.
882 Spaces are not allowed for trace labels. 8.10
883 Cannot set accumulate during roll mode display. 5.2, 8.4
884 Cannot change the History parameter when accumulate is ON. Turn OFF accumulate first. 8.4
885 P-P compression cannot be used to save when a record length is 1 K. 13.7
886 Event channels cannot be displayed at the current record length. 7.2, 5.21
