Brooks Marathon Express - Page 197

Brooks Automation 9. Maintenance and Repair
Part Number: 605914 Rev. B Repair Procedures
RequiredTools
l
AsetofHexwrenchesinmetricsizes
l
Adjustableliftorhoist(optional)
ReplacementStrategy
Turnoffanddisconnectallpower,communications,andairconnectionsasdetailedin"Shut-down"
onpage1.Allrobotstationsmustbeverified,andretaughtifnecessary,aftermakinganychanges
totherobot.
TheMarathonExpressmaybeusedinanenvironmentwherehazardousmaterials
arepresent,andsurfacesmaybecontaminatedbythosematerials.Refertothe
facility’sMaterialSafetyDataSheetsforthosematerialstodetermineproper
handlingandfollowthefacility’sprocedurestocertifytheenvironmentissafe.

Disposeofcleaningclothsperthefacility’sproceduresandlocalregulations.

Lockout / Tagout
Workingwithenergizedequipmentmaycausesuddenmovementorelectricalshockand
mayresultindeathorseriousinjury.
l
Allenergymustberemovedfromtheequipmentperthefacility’s
Lockout/Tagoutprocedurebeforeservicing.
l
Iflocalproceduresarenotavailable,followtheprocedureforLockout/Tagoutin
OSHA Standard 29CFR 1910.147.

Procedure
TherobotisreplacedfromthetopoftheMarathonExpressvacuumchamber.
Therobotarmsarereplacedfromthetopofthechamber.
Theendeffectorsmaybeadjustedorreplacedfromthetopofthechamber.
