11. Field Replaceable Units Marathon Express
Marathon Express Part Number: 605914 Rev. B
Figure 11-5: Robot FRUs
Number Description
1 ASSY,POWERPACKWITHFEET
2
ASSY,MAG7.1,35Z,0DEG,MX,
I/O,C5
3 ASSY,SINGLEARM,MAG7
4 ASSY,DUALARM,MAG7
5
1
ASSY,ENDEFFECTOR


1
Notethatchangingendeffectorstodifferentpartnumbersrequiresanewapplicationnumberfortherobotandmay
requireadditionalchangestotheconfigurationoftheMarathonExpresstoensureproperoperation.
214
