1. Introduction Marathon Express
Specifications Part Number: 605914 Rev. B
Specification Value
ElectricalSystem
Japan, USA:
200-208VAC@50/60Hz,twophase(phasetophaseorphasetoneutral),8A,based
onconfigurationandoperatingmode.
Inrushcurrent<38Amaxfor1/2to1cycle
OvervoltageCategoryII
Thesystemmustbeinstalledontheloadsideofausersupplied10,000AICrated,
UL489/IEC60947-2compliantbranchcircuitbreaker(circuitbreakersuppliedwithGen5
ENsystemACPDis5,000AIC).

Europe, Korea, Israel:
220-240VAC@50/60Hz,singlephase(phasetoneutral),8A,basedonconfiguration
andoperatingmode.
Inrushcurrent<38Amaxfor1/2to1cycle
OvervoltageCategoryII
Thesystemmustbeinstalledontheloadsideofauser-supplied10,000AICrated,
UL489/IEC60947-2compliantbranchcircuitbreaker(circuitbreakersuppliedwithGen5
ENsystemACPDis5,000AIC).
ElectricalHeater
Three phase star (Y) connection:
50/60Hz(Europe,Korea,Israel)
220VAC@9.45Aperphase,totalpower5.7kVA
230VAC@9.88Aperphase,totalpower6.2kVA
240VAC@10.31Aperphase,totalpower6.8kVA
HeaterPowerSupplyincorporatesa10,000AICrated,
UL489/IEC60947-2compliant,branchcurcuitbreaker.

Delta connection:
50/60Hz(Japan,USA)
200VAC@15.58Aperphase,totalpower5.7kVA
208VAC@16.85Aperphase,totalpower6.2kVA
HeaterPowerSupplyincorporatesa10,000AICrated,
UL489/IEC60947-2compliant,branchcurcuitbreaker.
