Danfoss VLT series Programming Guide

Attribute Value
Value range See Table 7.132.
Default value –
Sub-index 0x03
LCP parameter number –
Description CAM parsing error info
Access Read only
Data type UNSIGNED32
PDO mapping Optional
Value range See Table 7.132.
Default value –
Table 7.129 0x3810: CAM Prole 1
NOTICE
Objects 0x3811 to 0x3817 are the same as CAM prole 1 (0x3810) as shown in Table 7.129. Only the CAM prole
number increases by 1 for each object.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Parse CAM data reserved cyclic/non-cyclic master abs/rel slave abs/rel
MSB LSB
Table 7.130 CAM Conguration
Bit Value Denition
0 0 Slave position is an absolute value.
1 Slave position is a relative value.
1 0 Master position is an absolute value.
1 Master position is a relative value.
2 0 Axis repeats the execution of the CAM in cyclic mode.
1 Axis stops after 1 execution of the CAM in non-cyclic mode.
15 0 The servo drive resets this bit automatically to 0 if the parsing was started.
1 Triggers a new CAM parsing (needed if new CAM data was transferred over SDO and if the CAM data
was transferred as a le).
Table 7.131 Denition of Bits of the CAM Slave Table Selector
Both supported CAM types can be executed in cyclic and non-cyclic mode:
•
Cyclic mode: Repeats the execution of the CAM prole continuously on the master cycle basis.
•
Non-cyclic mode: The CAM prole is only run once. If the master position is already outside of the CAM prole, the
slave axis stays in synchronized motion and keeps the last position.
CAM parsing state
(sub-index 02)
Description CAM parsing error information (sub-index 03)
Byte 0 Byte 1 Byte 2 Byte 3
0x0000 No error/Valid CAM prole Reserved
0x0001 File not found. Reserved
0x0002 Error in 1 of the elements
controlParam.
Number of the set Reserved
0x0004 Prole currently active. No parsing
possible.
Reserved
0x0005 Out of CAM memory (CAM prole
is too large).
Reserved
Servo Drive Parameter Descr...
VLT
®
Integrated Servo Drive ISD
®
510 System
292 Danfoss A/S © 01/2017 All rights reserved. MG36D102
77
