CAM parsing state
(sub-index 02)
Description CAM parsing error information (sub-index 03)
Byte 0 Byte 1 Byte 2 Byte 3
0x0007 Advanced CAM only: Wrong node
type.
Node ID Segment ID (non-tting)
0x0009 Advanced CAM only: Unknown
node type.
Number of Element in Node section Normal: 0
EventSegmentContainer: segment
ID
0x000A Advanced CAM only: Start node
has wrong type.
Segment ID Start node ID
0x000B CAM has <2 nodes. Reserved
0x000C Basic CAM only: Parameter is out
of range.
Type of parameter:
0: Reserved
1: Master position
2: Slave position
3: Velocity
4: Acceleration
Data point index Reserved
0x000D Basic CAM only: A mandatory
parameter is missing.
0x000E Advanced CAM only: End node
has wrong type.
Segment ID End node ID
0x000F Parameter in header has wrong
range.
Parameter ID Reserved
0x0010 A mandatory parameter is missing
in the header.
Parameter type (see Table 7.133). Reserved
0x0011 CAM le is empty Reserved
0x0012 CAM storage buer not ready. Reserved
0x0013 CAM storage buer too small. Reserved
0x0014 CAM corrupt le. Reserved
0x0015 Node allocation overow. Node ID Reserved
0x0016 Segment allocation overow. Segment ID Start node ID
0x0017 Multiple segments as default. Segment ID Start node ID
0x0018 Advanced CAM only: Unknown
segment type.
Number of elements in
segment section.
Reserved
0x0019 Starting node failure. 1: Not found
2: Wrong type
3: No following
segment
Reserved
0x001A Advanced CAM only: node
parameter is out of range.
Parameter type (see Table 7.134 and
Table 7.135).
Node type
0: Reserved
1: Guide node
2: Event node
Node ID
0x001B Advanced CAM only: A mandatory
node parameter is missing.
0x001C Advanced CAM only: segment
parameter is out of range.
Parameter type (see Table 7.136 to
Table 7.146).
Segment type
0: Reserved
1: Guide poly
5: Move distance
6: Flying stop
7: Return
8: Event segment
container
0x50: Time poly
0x51: Velocity
0x52: Torque
0x53: Sync
Segment ID
0x001D Advanced CAM only: A mandatory
segment parameter is missing.
0x001E Only 1 friction segment allowed. Segment ID Reserved
0x0020 Undened CAM le type. Reserved
Servo Drive Parameter Descr... Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 293
7 7
