Danfoss VLT series Programming Guide

Attribute
Mandatory/
optional
(+default
value)
Value range/
allowed values
Description
numerator M Same as for object
0x3808, sub-index
1.
See object
0x3808, sub-
index 1.
denominat
or
M Same as for object
0x3808, sub-index
2.
See object
0x3808, sub-
index 2.
Table 2.7 Attributes for Element masterScaling
The CamProle element contains an optional element
slaveScaling which denes the scaling factor for the axis. If
this element is missing, the values from the object
dictionary are used (see chapter 7.14.10 Parameter: CAM
Slave Scaling (0x3809)). The same value range applies as
described for the objects in the object dictionary.
Attribute
Mandatory/
optional
(+default value)
Value range/
allowed values
Description
numerator M Same as for
object 0x3809,
sub-index 1.
See object
0x3809, sub-
index 1.
denominat
or
M Same as for
object 0x3809,
sub-index 2.
See object
0x3809, sub-
index 2.
Table 2.8 Attributes for Element slaveScaling
Another optional element is the controlParam1, and/or
controlParam2 element, where the control loop parameters
are dened. Those 2 elements allow the automatic
overwriting of the 2 sets of control parameters (in the
object dictionary) on activation of the CAM. Both objects
are optional and can be present independently of each
other.
controlParam1 refers to the 1
st
set of control parameters
(see chapter 7.6.5.1 Parameters 51-10 to 51-15: Speed
Controller Parameters (0x2012) and
chapter 7.6.4.1 Parameters 51-16 and 51-17: Position
Controller Parameters (0x2013)), whereas controlParam2
refers to the 2
nd
set of control parameters (see
chapter 7.6.5.2 Parameters 51-20 to 51-25: Speed Controller
Parameters 2 (0x2014) and chapter 7.6.4.2 Parameters 51-26
and 51-27: Position Controller Parameters 2 (0x2015)).
Attribute
Mandatory/
optional
(+default
value)
Value range/
allowed values
Description
speedP,
speedI,
speedD,
inertia
M Float, same as for
object 0x2012.
See object
0x2012.
positionP,
positionD
M Float, same as for
object 0x2013.
See object
0x2013.
Table 2.9 Attributes for Element controlParam1
Attribute
Mandatory/
optional
(+default
value)
Value range/
allowed values
Description
speedP,
speedI,
speedD,
inertia
M Float, same as for
object 0x2014.
See object
0x2014.
positionP,
positionD
M Float, same as for
object 0x2015.
See object
0x2015.
Table 2.10 Attributes for Element controlParam2
The optional element followingError denes the following
error settings for the CAM. The mandatory attribute
windowRev refers to object 0x6065 (see
chapter 7.22.1.1 Parameter: Following Error Window (0x6065)),
but the value must be given in revolutions. The mandatory
attribute time gives the time in milliseconds (see
chapter 7.22.1.2 Parameter: Following Error Time Out
(0x6066)). The following error behavior applies here.
Attribute
Mandatory/
optional
(+default
value)
Value
range/
allowed
values
Description
windowR
ev
M Float See object 0x6065 for
description, however this
value must be given in
revolutions. The servo
drive automatically
recalculates the value to
the value required for
object 0x6065.
time M Same as
for object
0x6066.
See object 0x6066.
Table 2.11 Attributes for Element followingError
The rest of the CamProle element depends on the prole
type (basic or advanced) and is described in the following
chapters.
Servo Drive Operation
VLT
®
Integrated Servo Drive ISD
®
510 System
42 Danfoss A/S © 01/2017 All rights reserved. MG36D102
