Configuring System Information 123
Defining IP Interfaces Using CLI Commands
The following table summarizes the equivalent CLI commands for setting fields displayed in the
IP Interface Parameters
page.
The following is an example of the CLI commands:
Defining DHCP IP Interface Parameters
console# show ip interface vlan 1
Output
Table 6-27. IP Interface Parameters CLI Commands
CLI Command Description
ip address ip-address {mask |
prefix-length}
Sets an IP address.
no ip address [ip-address] Removes an IP address
show ip interface [ethernet
interface-number | vlan vlan-
id | port-channel number]
Displays the usability status of interfaces
configured for IP.
Console (config)# interface vlan 1
Console (config-if)# ip address 131.108.1.27 255.255.255.0
Console (config-if)# no ip address 131.108.1.27
Console (config-if)# exitconsole# show ip interface vlan 1
Output

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
