Dell PowerConnect 5324 User Manual

Configuring Device Information 251
The following is an example of the CLI commands:
Configuring Rapid Spanning Tree
While Classic Spanning Tree guarantees preventing L2 forwarding loops in a general network
topology, convergence can take up to 30-60 seconds. The convergence time is considered too long
for many applications. When network topology allows, faster convergence may be possible. The
Rapid Spanning Tree Protocol (RSTP) detects and uses of network topologies that provide faster
convergence of the spanning tree, without creating forwarding loops.
RSTP has the following different port states:
• Disabled
• Learning
• Discarding
• Forwarding
Rapid Spanning Tree is enabled on the
STP Global Settings page. To open the Rapid Spanning
Tree (RSTP)
page, click Switch → Spanning Tree → Rapid Spanning Tree in the tree view.
show spanning-tree [ ethernet interface
| port-channel port-channel-number]
Displays spanning tree configuration.
show spanning-tree [detail] [active |
blockedports]
Displays detailed spanning tree
information on active or blocked ports
console(config)# interface port-channel 1
console(config-if)# spanning-tree port-priority 16
Table 7-62. STP LAG Settings CLI Commands
CLI Command Description

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
