Dell PowerConnect 5324 User Manual

208 Configuring Device Information
www.dell.com | support.dell.com
Authentication Method — The method by which the last session was authenticated. The possible
field values are:
Remote — The user was authenticated from a remote server.
None — The user was not authenticated.
MAC Address — The client (supplicant) MAC address.
Displaying the Authenticated Users Table
1 Open the Add User Name page.
2 Click Show All .
The
Authenticated Users Table opens:
Figure 7-85. Authenticated Users Table
Authenticating Users Using the CLI Commands
The following table summarizes the equivalent CLI commands for authenticating users as
displayed in the
Add User Name page.
Table 7-51. Add User Name CLI Commands
CLI Command Description
show dot1x users [username
username
Displays 802.1X users for the device

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
