Dell PowerConnect 5324 User Manual

Configuring System Information 189
Downloading Files Using CLI Commands
The following table summarizes the equivalent CLI commands for setting fields displayed in the
File Download From Server
page.
The following is an example of the CLI commands:
Uploading Files
The File Upload to Server page contains fields for uploading the software from the TFTP server to
the device. The Image file can also be uploaded from the
File Upload to Server page. To open the
File Upload to Server page, click System → File Management → File Upload in the tree view.
Table 6-45. File Download CLI Commands
CLI Command Description
copy source-url destination-
url [snmp]
Copies any file from a source to a destination.
console# copy running-config tftp://11.1.1.2/pp.txt
NOTE: Each "!" indicates that ten packets were successfully transferred.
Accessing file 'file1' on 172.16.101.101.
Loading file1 from 172.16.101.101:
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! [OK]
Copy took 0:01:11 [hh:mm:ss]

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
