Dell PowerConnect 5324 User Manual

Configuring Device Information 279
Assigning Ports to LAGs Using CLI Commands
The following table summarizes the equivalent CLI commands for assigning ports to LAGs as
displayed in the
LAG Membership page.
The following is an example of the CLI commands:
Multicast Forwarding Support
Multicast forwarding allows a single packet to be forwarded to multiple destinations. L2 Multicast
service is based on L2 switch receiving a single packet addressed to a specific Multicast address.
Multicast forwarding creates copies of the packet, and transmits the packets to the relevant ports.
The device supports:
•
Forwarding L2 Multicast Packets — Enabled by default, and not configurable.
• Filtering L2 Multicast Packets — Enables forwarding of Layer 2 packets to interfaces. If
Multicast filtering is disabled, Multicast packets are flooded to all relevant ports.
To open the
Multicast Support page, click Switch → Multicast Support in the tree view.
Defining Multicast Global Parameters
Table 7-73. LAG Membership CLI Commands
CLI Command Description
interface port-channel port-
channel-number
Enters the interface configuration mode of a
specific port-channel.
channel-group
port-
channel-number
mode
{on | auto}
Associates a port with a port-channel. Use the
no form of this command to remove the
channel-group configuration from the
interface.
show interfaces port-channel
[port-channel-number]
Displays port-channel information.
console# config
console(config)# interface ethernet g1
console(config-if)# channel-group 1 mode on
console(config-if)# 01-Jan-2000 01:47:18 %LINK-W-Down: ch1
console(config-if)#
NOTE: The system supports Multicast filtering for 63 Multicast groups.

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
