Defining Protocol Ports Using CLI Commands
The following table summarizes the equivalent CLI command for for defining Protocol Ports.
The following example sets a protocol-based classification rule of protocol group 1 to VLAN 8:
Configuring GVRP
GARP VLAN Registration Protocol (GVRP) is specifically provided for automatic distribution of
VLAN membership information among VLAN-aware bridges. GVRP allows VLAN-aware bridges to
automatically learn VLANs to bridge ports mapping, without having to individually configure each
bridge and register VLAN membership.
To ensure the correct operation of the GVRP protocol, it is advised to set the maximum number of
GVRP VLANs equal to a value which significantly exceeds the sum of:
• The number of all static VLANs both currently configured and expected to be configured.
• The number of all dynamic VLANs participating in GVRP, both currently configured (initial
number of dynamic GVRP VLANs is 128) and expected to be configured.
Table 7-70. Protocol Port CLI Commands
CLI Command Description
switchport general map
protocols-group group
vlan vlan-id
Sets a protocol-based classification rule.
Console (config-if)# switchport general map protocols-group 1
vlan 8

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
