Dell PowerConnect 5324 - Fiber Optic Cable Test CLI Commands

Configuring System Information 143
The following is an example of the CLI command:
The
Optical Transceiver Diagnostics Table contains the following columns:
•
Temp — Internally measured transceiver temperature.
•
Voltage — Internally measured supply voltage.
•
Current — Measured TX bias current.
•
Output Power — Measured TX output power in milliwatts.
•
Input Power — Measured RX received power in milliwatts.
•
TX Fault — Transmitter fault.
NOTE: Finisair transceivers do not support the transmitter fault diagnostic testing.
Table 6-34. Fiber Optic Cable Test CLI Commands
CLI Command Description
show fiber-ports optical-transceiver
[interface][detailed]
Displays the optical transceiver
diagnostics.
console> enable
Console# show fiber-ports optical-transceiver
Power
Port Temp
(C)
Voltage
(Volt)
Current
(mA)
Output
(mWatt)
Input
(mWatt)
TX
Fault
LOS
g1 W OK E OK OK OK OK
g2 OK OK OK OK OK E OK
g3 Copper
Temp – Internally measured transceiver temperature.
Voltage - Internally measured supply voltage.
Current – Measured TX bias current.
Output Power – Measured TX output power.
Input Power – Measured RX received power.
Tx Fault – Transmitter fault
LOS – Loss of signal
