Dell PowerConnect 5324 User Manual

328 Viewing Statistics
www.dell.com | support.dell.com
5 Click Apply Changes .
The RMON alarm is added, and the device is updated.
Modifying an Alarm Table Entry
1 Open the RMON Alarms page.
2 Select an entry in the Alarm Entry drop-down menu.
3 Modify the fields in the dialog as required.
4 Click Apply Changes .
The entry is modified, and the device is updated.
Displaying the Alarm Table
1 Open the RMON Alarms page.
2 Click Show All .
The
Alarms Table page opens.
Deleting an Alarm Table Entry
1 Open the RMON Alarms page.
2 Select an entry in the Alarm Entry drop-down menu.
3 Select the Remove check box.
4 Click Apply Changes .
The selected entry is deleted, and the device is updated.
Defining Device Alarms Using the CLI Commands
The following table summarizes the equivalent CLI commands for defining device alarms.
Table 8-89. Device Alarm CLI Commands
CLI Command Description
rmon alarm index variable interval
rthreshold fthreshold revent fevent
[type type] [startup direction] [owner
name]
Configures RMON alarm conditions.
show rmon alarm-table Displays summary of the alarm table.
show rmon alarm Displays RMON alarm configuration.

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
