Dell PowerConnect 5324 User Manual

138 Configuring System Information
www.dell.com | support.dell.com
Configuring ARP Using the CLI Commands
The following table summarizes the equivalent CLI commands for setting fields displayed in the
ARP Settings
page.
The following is an example of the CLI commands:
Table 6-32. ARP Settings CLI Commands
CLI Command Description
arp ip_addr hw_addr
{ethernet interface-number |
vlan vlan-id | port-channel
number}
Adds a permanent entry in the ARP cache.
arp timeout seconds Configures how long an entry remains in the ARP
cache.
clear arp-cache Deletes all dynamic entries from the ARP cache
show arp Displays entries in the ARP Table.
no arp Removes an ARP entry from the ARP Table.
Console(config)# arp 198.133.219.232 00-00-0c-40-0f-bc
Console (config)# exit
Console# arp timeout 12000
Console# show arp
ARP timeout: 80000 Seconds
Interface IP address HW address Status
--------- ---------- ---------- ------
g1 10.7.1.102 00:10:B5:04:DB:4B Dynamic
g2 10.7.1.135 00:50:22:00:2A:A4 Static

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
