Configuring Device Information 283
Adding Bridge Multicast Addresses
1 Open the Bridge Multicast Group page.
2 Click Add .
The
Add Bridge Multicast Group page opens:
Figure 7-112. Add Bridge Multicast Group
3
Define the VLAN ID and New Bridge Multicast Address fields.
4 Toggle a port to S to join the port to the selected Multicast group.
5 Toggle a port to F to forbid adding specific Multicast addresses to a specific port.
Table 7-75. IGMP Port/LAG Members Table Control Settings
Port Control Definition
D The port/LAG has joined the Multicast group
dynamically in the Current Row.
S Attaches the port to the Multicast group as
static member in the Static Row.
The port/LAG has joined the Multicast group
statically in the Current Row.
F Forbidden.
Blank The port is not attached to a Multicast group.
