Configuring Device Information 213
Configuring Locked Port Security with CLI Commands
The following table summarizes the equivalent CLI commands for configuring Locked Port
security as displayed in the
Port Security page.
The following is an example of the CLI commands:
Table 7-52. Port Security CLI Commands
CLI Command Description
shutdown
Disables interfaces.
set interface active {ethernet
interface | port-channel port-
channel-number}
Reactivates an interface that is shutdown due to
port security reasons.
port security [forward |
discard | discard-shutdown]
[trap seconds]
Locks learning of new addresses on an interface.
show ports security {ethernet
interface | port-channel port-
channel-number}
Displays port lock status.
Console # show ports security
Port Status Action Trap Frequency Counter
----- ------- ------- ------- --------- --------
g7 Unlocked Discard Enable 100 88
g8 Unlocked Discard,
Shutdown
Disable
g3 Unlocked - - - -

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
