Dell PowerConnect 5324 User Manual

160 Configuring System Information
www.dell.com | support.dell.com
Defining a New User:
1 Open the Local User Database page.
2 Click Add .
The
Add User page opens:
Figure 6-60. Add User
3
Define the fields.
4 Click Apply Changes .
The new user is defined, and the device is updated.
Displaying the Local User Table:
1 Open the Local User Database page.
2 Click Show All.
The Local User Table opens:
Figure 6-61. Local User Table Page
Deleting Users:
1 Open the Local User Database page.
2 Click Show All.
The Local User Table opens.

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
