Dell PowerConnect 5324 User Manual

258 Configuring Device Information
www.dell.com | support.dell.com
The VLAN Port Membership Table displays the ports and the ports states, as well as LAGs.
Assigning Ports to a VLAN Group
1 Open the VLAN Membership page.
2 Click the VLAN ID or VLAN Name option button and select a VLAN from the drop-down
menu.
3 Select a port in the Port Membership Table , and assign the port a value.
4 Click Apply Changes .
The port is assigned to the VLAN group, and the device is updated.
Deleting a VLAN
1 Open the VLAN Membership page.
2 Click the VLAN ID or VLAN Name option button and select a VLAN from the drop-down
menu.
3 Select the Remove VLAN check box.
4 Click Apply Changes .
The selected VLAN is deleted, and the device is updated.
Assigning Ports to VLAN Groups Using CLI Commands
The following table summarizes the equivalent CLI commands for assigning ports to VLAN
groups.
Table 7-66. Port-to-VLAN Group Assignments CLI Commands
CLI Command Description
switchport general acceptable-frame-
types tagged-only
Discards untagged frames at ingress.
switchport forbidden vlan {add
vlan-list | remove vlan-
list
}
Forbids adding specific VLANs to the
port.
switchport mode {access | trunk |
general}
Configures the VLAN membership
mode of a port.
switchport access vlan vlan-id Configures the VLAN ID when the
interface is in access mode.
switchport trunk allowed vlan {add
vlan-list | remove vlan-list}
Adds or removes VLANs from a trunk
port.
switchport trunk native vlan vlan-id Defines the port as a member of the
specified VLAN, and the VLAN ID as
the "port default VLAN ID (PVID)".

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
