Configuring Device Information 257
The following is an example of the CLI commands:
VLAN Port Membership Table
The
VLAN Port Membership Table
contains a Port Table for assigning ports to VLANs. Ports are
assigned VLAN membership by toggling through the Port Control settings. Ports can have the
following values:
NOTE: Ports which are LAG members are not displayed in the VLAN Port Membership Table.
console(config)# vlan database
console(config-vlan)# vlan 1972
console(config-vlan)# exit
console(config)# interface vlan 1972
console(config-if)# name Marketing
console(config-if)# exit
console(config)#
Table 7-65. VLAN Port Membership Table
Port Control Definition
T The interface is a member of a VLAN. All
packets forwarded by the interface are tagged.
The packets contain VLAN information.
U The interface is a VLAN member. Packets
forwarded by the interface are untagged.
F The interface is denied membership to a VLAN.
Blank The interface is not a VLAN member. Packets
associated with the interface are not forwarded.
