Dell PowerConnect 5324 User Manual

194 Configuring System Information
www.dell.com | support.dell.com
Figure 6-79. General Settings
Attribute — The general setting attribute.
Current — The currently configured value.
After Reset — The future (after reset) value. By entering a value in the After Reset column,
memory is allocated to the field table.
Max RAM Log Entries (20-400) — The maximum number of RAM Log entries. When the Log
entries are full, the log is cleared and the Log file is restarted.
Jumbo Frames — Enables or disables the Jumbo Frames feature. Jumbo Frames enable the
transportation of identical data in fewer frames. This ensures less overhead, lower processing time,
and fewer interrupts.
Viewing RAM Log Entries Counter Using the CLI Commands
The following table summarizes the equivalent CLI commands for setting fields displayed in the
General Settings
page.
Table 6-48. General Settings CLI Commands
CLI Command Description
logging buffered size number Sets the number of syslog messages stored in the
internal buffer (RAM).
port jumbo-frame Enables jumbo frames for the device.

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
