230 Configuring Device Information
www.dell.com | support.dell.com
4
Select the source port from the
Source Port
drop-down menu.
5
Define the
Ty p e
field.
6
Click
Apply Changes
.
The new source port is defined, and the device is updated.
Deleting a Copy Port from a Port Mirroring Session
1
Open the
Port Mirroring
page.
2
Select the
Remove
check box.
3
Click
Apply Changes
.
The selected port mirroring session is deleted, and the device is updated.
Configuring a Port Mirroring Session Using CLI Commands
The following table summarizes the equivalent CLI commands for configuring a Port Mirroring
session as displayed in the
Port Mirroring
page.
The following is an example of the CLI commands:
Table 7-56. Port Mirroring CLI Commands
CLI Command Description
port monitor src-interface [rx | tx] Starts a port monitoring session.
Console(config)# interface ethernet g1
Console(config-if)# port monitor g8
Console# show ports monitor
Source Port Destination Port Type Status VLAN Tagging
----------- ---------------- ------------ ------- ------------
g8 g1 RX, TX Active No
g2 g8 RX, TX Active No
g18 g8 Rx Active No
