Device Specifications 351
Device Specifications
This appendix includes the information needed for running the device.
Port and Cable Specifications
This section describes the port specifications.
Port Specifications
The following table describes the device port types, as well as, a description of the port types.
Table 10-99. Port Specifications
Device Specification
PowerConnect 5324
24 GE ports
4 SFP ports
RS-232 Console port
Port Types
RJ-45
•10 Base-T
100 Base-T
1000 Base-T
SFP Supports Standard Small Form-Factor
Gigabit Plug Transceivers
Port Settings
Auto-negotiation for speed, duplex mode
and flow control
Back Pressure
Head of Line Blocking
Auto MDI/MDIX
Port Mirroring
Broadcast Storm Control

Table of Contents

Other manuals for Dell PowerConnect 5324

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell PowerConnect 5324 and is the answer not in the manual?

Dell PowerConnect 5324 Specifications

General IconGeneral
Switching Capacity48 Gbps
VLAN SupportYes
Rack MountableYes
Device TypeSwitch
MAC Address Table Size8K entries
RAM64 MB
Flash Memory8 MB
Power DeviceInternal power supply
Voltage RequiredAC 120/230 V (50/60 Hz)
Jumbo Frame SupportYes
Ports24 x 10/100/1000 + 2 x SFP
ManagementWeb-based, SNMP, CLI
Enclosure TypeRack-mountable
Routing ProtocolStatic IP routing
Remote Management ProtocolSNMP 1, 2, 3
FeaturesFlow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature0 °C to 45 °C
Storage Temperature-20 °C to 70 °C
Humidity5% to 95% (non-condensing)
LayerLayer 2
