322 Viewing Statistics
www.dell.com | support.dell.com
The Add an Event Entry page opens.
3 Complete the information in the dialog and click Apply Changes .
The
Event Table entry is added, and the device is updated.
Modifying an RMON Event
1 Open the RMON Events Control page
2 Select an entry in the Event Table .
3 Modify the fields in the dialog and click Apply Changes .
The
Event Table entry is modified, and the device is updated.
Deleting RMON Event Entries
1 Open the RMON Events Control page.
2 Click Show All .
The
Events Table page opens.
3 Select Remove for the event(s) that need to be deleted and then click Apply Changes .
The selected table entry is deleted, and the device is updated.
NOTE: A single event entry can be removed from the RMON Events Control page by selecting the
Remove check box on that page.
Defining Device Events Using the CLI Commands
The following table summarizes the equivalent CLI commands for defining device events.
Table 8-87. Device Event Definition CLI Commands
CLI Command Description
rmon event index type [community
text] [description text] [owner
name]
Configures RMON events.
show rmon events Displays RMON event table.

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
