Dell PowerConnect 5324 User Manual

Configuring Device Information 225
Enabling Storm Control
A Broadcast Storm is a result of an excessive amount of broadcast messages simultaneously
transmitted across a network by a single port. Forwarded message responses are heaped onto the
network, straining network resources or causing the network to time out.
The system measures the incoming Broadcast and Multicast frame rate separately on each port,
and discard frames when the rate exceeds a user-defined rate.
The
Storm Control page provides fields for enabling and configuring Storm Control. To open the
Storm Control page, click Switch → Ports → Storm Control in the tree view.
Figure 7-92. Storm Control
Count Multicast with Broadcast — Counts Broadcast and Multicast traffic. The possible field
values are:
–
Enable — Counts Broadcast and Multicast traffic.
ch3
ch4
ch5
ch6
ch7
ch8
console#

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
