Dell PowerConnect 5324 User Manual

Introduction 19
Introduction
NOTICE: Before proceeding, read the release notes for this product. The release notes can be
downloaded from support.dell.com.
This User Guide contains the information needed for installing, configuring and maintaining the
PowerConnect device.
PowerConnect 5324
The PowerConnect 5324 has 24 Gigabit Ethernet ports. There are also four SFP fiber ports that are
designated as combo port alternatives to Ethernet ports 21-24. The combo ports are single ports
with two physical connections. When one is connected the other is disabled.
Figure 1-1 and Figure 1-2 illustrates the PowerConnect 5324 front and back panels.
Figure 1-1. PowerConnect 5324 Front Panel
Figure 1-2. PowerConnect 5324 Back Panel
Features
This section describes the device user-configured features. For a complete list of all updated device
features, refer to the latest software version Release Notes.

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
