Using Dell OpenManage Switch Administrator 67
Table 5-8. Led Indicators
NOTE: The Port LEDs are not reflected in PowerConnect front panel in the PowerConnect OpenManage
Switch Administrator. LED status can only be determined by viewing the actual device. For more
information about LEDs, see "LED Definitions".
Using the Switch Administrator Buttons
This section describes the buttons found on the OpenManage Switch Administrator interface.
Information Buttons
Information buttons provide access to on-line support and online help, as well as information
about the OpenManage Switch Administrator interfaces.
Device Management Buttons
Device Management buttons provide an easy method of configuring device information, and
includes the following:
Component Name
Port Indicators
Green The port is currently enabled.
Red An error has occurred on the port.
Blue The port is currently disabled.
Table 5-9. Information Buttons
Button Description
Support Opens the Dell Support page at
support.dell.com.
Help Online help containing information to assist in
configuring and managing the
device
. The
online help pages are linked directly to the page
currently open. For example, if the IP
Addressing page is open, the help topic for that
page opens when Help is clicked.
About Contains the version and build number and Dell
copyright information.
Log Out Logs out of the application and closes the
browser window.
