Dell PowerConnect 5324 User Manual

154 Configuring System Information
www.dell.com | support.dell.com
Figure 6-57. Authentication Profiles
Deleting an Authentication Profiles:
1 Open the Authentication Profiles page.
2 Click Show All .
The
Authentication Profile page opens.
3 Select an authentication profile.
4 Select the Remove check box.
5 Click Apply Changes .
The selected authenticating profile is deleted.
Configuring an Authentication Profile Using CLI Commands
The following table summarizes the equivalent CLI commands for setting fields displayed in the
Authentication Profiles
page.
Table 6-36. Authentication Profile CLI Commands
CLI Command Description
aaa authentication login
{default | list-name}
method1 [method2.]
Configures login authentication.
no aaa authentication login
{default | list-name
Removes a login authentication profile.

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
