330 Viewing Statistics
www.dell.com | support.dell.com
Viewing Charts
The
Chart
page contains links for displaying statistics in a chart form. To open the page, click
Statistics
→
Charts
in the tree view.
Viewing Port Statistics
The
Port Statistics
page contains fields for opening statistics in a chart form for port elements. To
open the
Port Statistics
page, click
Statistics
→
Charts
→
Ports
in the tree view.
Figure 8-128. Port Statistics
Interface Statistics
— Selects the type of interface statistics to open.
Etherlike Statistics
— Selects the type of Etherlike statistics to open.
RMON Statistics
— Selects the type of RMON statistics to open.
GVRP Statistics
— Selects the GVRP statistics type to open.
Refresh Rate
— Amount of time that passes before the statistics are refreshed.
Displaying Port Statistics
1
Open the
Port Statistics
page.
2
Select the statistic type to open.
3
Select the desired refresh rate from the
Refresh Rate
drop-down menu.
4
Click
Draw
.
