Dell PowerConnect 5324 User Manual

260 Configuring Device Information
www.dell.com | support.dell.com
The following is an example of the CLI commands:
Console (config)# vlan database
Console (config-vlan)# vlan 23-25
Console (config-vlan)# exit
Console (config)# interface vlan 23
Console (config-if)# name Marketing
Console (config-if)# exit
Console (config)# interface ethernet g8
Console (config-if)# switchport mode access
Console (config-if)# switchport access vlan 23
Console (config-if)# exit
Console (config)# interface ethernet g9
Console (config-if)# switchport mode trunk
Console (config-if)# swithport mode trunk allowed
vlan add 23-25
Console (config-if)# exit
Console (config)# interface ethernet g10
Console (config-if)# switchport mode general
Console (config-if)# switchport general allowed vlan
add 23,25 tagged
Console (config-if)# switchport general pvid 25

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
