Configuring Device Information 265
Ingress Filtering — Enables or disables Ingress filtering by the LAG. Ingress filtering discards
packets that are destined to VLANs of which the specific port is not a member.
Current Reserve VLAN — The VLAN currently designated as the reserved VLAN.
Reserve VLAN for Internal Use — The VLAN that is designated as the reserved VLAN after the
device is reset.
Assigning VLAN LAG Settings:
1 Open the VLAN LAG Setting page.
2 Select a LAG from the LAG drop-down menu and complete the fields on the page.
3 Click Apply Changes .
The VLAN LAG parameters are defined, and the device is updated.
Displaying the VLAN LAG Table
1 Open the VLAN LAG Setting page.
2 Click Show All .
The
VLAN LAG Table opens.
Assigning LAGs to VLAN Groups Using CLI Commands
The following table summarizes the equivalent CLI commands for assigning LAGs to VLAN
groups as displayed in the
VLAN LAG Setting page.
Table 7-68. LAG VLAN Assignments CLI Commands
CLI Command Description
switchport mode {access | trunk
| general}
Configures a port VLAN membership mode.
switchport trunk native vlan
vlan-id
Defines the port as a member of the specified
VLAN, and the VLAN ID as the port default
VLAN ID (PVID).
switchport general pvid vlan-id Configure the Port VLAN ID (PVID) when the
interface is in general mode.
switchport general allowed vlan
add vlan-list [tagged |
untagged]
Adds or removes VLANs from a general port.
switchport general acceptable-
frame-type tagged-only
Discards untagged packets at ingress.
switchport general ingress-
filtering disable
Disables port ingress filtering.

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
