268 Configuring Device Information
www.dell.com | support.dell.com
Assigning VLAN Protocol Group Settings
1
Open the
Protocol Group
page.
2
Complete the fields on the page.
3
Click
Apply Changes
.
The VLAN protocol group parameters are defined, and the device is updated.
Removing Protocols From the Protocol Group Table
1
Open the
Protocol Group
page.
2
Click
Show All
.
The
Protocol Group Table
opens.
3
Select
Remove
for the protocol groups that need to be removed.
4
Click
Apply Changes
.
The protocol is removed, and the device is updated.
Defining VLAN Protocol Groups Using CLI Commands
The following table summarizes the equivalent CLI commands for configuring Protocol Groups.
The following example maps ip-arp protocol to group "213":
Table 7-69. VLAN Protocol Groups CLI Commands
CLI Command Description
map protocol protocol [encapsulation]
protocols-group group
Console (config)# vlan database
Console (config-vlan)# map protocol ip-arp protocols-group 213
