Dell PowerConnect 5324 User Manual

Configuring Device Information 281
Bridge Multicast is enabled on the device.
Enabling IGMP Snooping on the Device
1 Open the Multicast Global Parameters page.
2 Select Enable in the IGMP Snooping Status field.
3 Click Apply Changes .
IGMP Snooping is enabled on the device.
Enabling Multicast Forwarding and IGMP Snooping Using CLI Commands
The following table summarizes the equivalent CLI commands for enabling Multicast forwarding
and IGMP Snooping as displayed on the
Multicast Global Parameters page.
The following is an example of the CLI commands:
Table 7-74. Multicast Forwarding and Snooping CLI Commands
CLI Command Description
bridge multicast filtering Enables filtering of Multicast addresses.
ip igmp snooping Enables Internet Group Membership
Protocol (IGMP) snooping.
Console (config)# bridge multicast filtering
Console (config)# ip igmp snooping

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
