Starting and Configuring the Device 45
------ Performing the Power-On Self Test (POST) ------
UART Channel Loopback Test........................PASS
Testing the System SDRAM..........................PASS
Boot1 Checksum Test...............................PASS
Boot2 Checksum Test...............................PASS
Flash Image Validation Test.......................PASS
BOOT Software Version 1.0.0.20 Built 22-Jan-2004 15:09:28
Processor: FireFox 88E6218 ARM946E-S , 64 MByte SDRAM.
I-Cache 8 KB. D-Cache 8 KB. Cache Enabled.
Autoboot in 2 seconds - press RETURN or Esc. to abort and enter
prom.
Preparing to decompress...
The boot process runs approximately 90 seconds.
The auto-boot message displayed at the end of POST (see the last lines) indicates that no
problems were encountered during boot.
During boot the
Startup menu can be used to run special procedures. To enter the Startup menu,
press <Esc> or <Enter> within the first two seconds after the auto-boot message is displayed.
If the system boot process is not interrupted by pressing <Esc> or <Enter>, the process
continues decompressing and loading the code into RAM. The code starts running from RAM and
the list of numbered system ports and their states (up or down) are displayed.
The following screen is an example configuration. Items such as addresses, versions, and
dates may differ for each device.
Decompressing SW from image-2
78c000
OK
Running from RAM...
*********************************************************************
*** Running SW Ver. 1.0.0.15 Date 03-Mar-2004 Time 10:41:14 ***
*********************************************************************

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
