Set the following parameters if Overwrite is selected for Payload ID.
See Sec. 5-30. "VIDEO PAYLOAD ID 1, 2."
HD Payload
ID
Enable
Disable
Enable
Enables/disables insertion of payload identifiers
into HD-SDI.
CS/DR
Embedded
Auto
Auto
Manual
Sets the Payload ID codes insertion mode for
Dynamic Range and Color Space.
Auto: Automatically inserts the codes according to
the Dynamic Range Conv. setting. (See Sec. 5-4.
"INPUT / OUTPUT GAMMA / COLOR.")
Bypass: Payload ID codes in input signal are
inserted. If set to Operate, Payload ID codes
suitable to output gamma and color gamut are
inserted.
Manual: Inserts the codes according to the
following parameter settings.
Color
Space
Rec.709
Rec.709
VANC
UHDTV
Unknown
Selects a color space (gamut).
Dynamic
Range
SDR
SDR
HLG
PQ
Unspecified
Selects a dynamic range.
◆ Vertical Ancillary Multiplex
Item
Default
Setting
Description
Mode
Pass
Pass
Rewrite
Selects the VANC data insertion mode to each FS
output.
Pass: Passes through the input VANC data without
processing. If input and output signal formats are
different, the VANC space becomes blank.
Rewrite: Outputs black in the VANC area. If ARIB
STD-B37 STD-B39 and/or User Packet are set to
other than Disable in the ANC DATA INSERTION
menu (See Sec. 5-37.) and the packet is included
in input signal, it is inserted in the proper space on
the output signal.
Set the following parameters if Mode is set to Rewrite.
ARIB
STD-B37
Disable
Disable
Through
Disable: Inserts no data packets.
Through: Inserts data packets of input without
change.
Overwrite: Inserts the internally generated control
signal packet defined by ARIB STD-B39.
Audio data information to be inserted should be set
under Audio Method and Audio Mode Data below.
See Sec. 5-37. “ANC DATA INSERTION” for more
details.
ARIB
STD-B39
Disable
Disable
Through
Overwrite
User Packet
(Support
planned)
Disable
Disable
Through
Set the following parameters if ARIB STD-B39 is set to Overwrite.
Audio
Method
Pass
Pass
Overwrite
Pass: Passes the input signal ARIB STD-B39
Audio Mode data through to the output or
overwrites the new information if input and output
audio formats are different.
Overwrite: Replaces the audio information to the
one set under Mode Data if ARIB STD-B39 Audio
Mode data is inserted in the input signal.
Audio
Mode Data
Unused
-
Selects the Audio Mode data from the table in Sec.
6-4.
