14-5. FA-9600 Event Editor
◆ System Requirements
The Event Editor can run in the same system as FA-9600 Windows GUI. (See Sec. 9-1. “System
Requirements.”)
◆ Installing and Using FA-9600 Event Editor
(1) Open the FA-9600 Event Editor folder in the supplied CD-ROM and double-click the Setup
file to start the setup wizard.
(2) After installation, double-click the Event Editor icon on the desktop to start the Event Editor.
(3) Check the desired checkboxes to select items to be saved from all event items.
◆ File Menu
Menu
Description
Import Event File
Loads an event file stored in
the PC to the Event Editor.
Export Event File
Saves the edited event items
to an event file in the PC.
Connect FA-9600
Opens the FA-9600
communication window.
Exit
Closes the Event Editor.
