58
5-21. ADJUST TIMING(FA-96UDC)
Simultaneous 4K/HD
Dual HD
3D-LUT (FS1)
Required
Option
FA-96UDC
â—† ADJUST TIMING
Item
Default
Setting
Description
Mode
Frame
Frame
Minimum
Adjustable
Selects the Conversion 1 or 2 output timing (delay
amount).
Frame: Outputs at the same timing (delayed in frames)
as that of the FS.
Minimum: Outputs with the minimum delay.
Adjustable: Outputs at the timing adjusted by the
following parameters.
If Mode is set to Adjustable, use the following parameters to adjust the output timing.
Horizontal
0 Clock
-2750 to 2750
Clock
Adjusts the horizontal timing. Adjustable range (see the
table below) is defined by video format. If a limit is
exceeded, one line is internally added or subtracted.
Vertical
0 Line
-563 to 563
Line
Adjusts the vertical timing. Adjustable range (see the
table below) is defined by video format. If a limit is
exceeded, plus and minus values are internally inverted.
<Horizontal/Vertical adjustable ranges>
Video format
Horizontal range
Vertical range
525/59.94i
-858
to
858
-263
to
263
625/50i
-864
to
864
-313
to
313
720/23.98p,24p
-2063
to
2063
-375
to
375
720/25p
-1980
to
1980
-375
to
375
720/29.97p, 30p
-1650
to
1650
-375
to
375
720/50p
-990
to
990
-375
to
375
720/59.94p, 60p
-825
to
825
-375
to
375
1080/23.98PsF, 23.98p, 24PsF, 24p
-1375
to
1375
-563
to
563
1080/24PsF, 25p
-1320
to
1320
-563
to
563
1080/29.97PsF, 29.97p, 30PsF, 30p
-1100
to
1100
-563
to
563
1080/50i
-1320
to
1320
-563
to
563
1080/59.94i, 60i
-1100
to
1100
-563
to
563
1080/47.95p, 48p(Level-A)
-1375
to
1375
-563
to
563
1080/47.95p, 48p(Level-B)
-2750
to
2750
-563
to
563
1080/50p(Level-A)
-1320
to
1320
-563
to
563
1080/50p(Level-B)
-2640
to
2640
-563
to
563
1080/59.94p, 60p(Level-A)
-1100
to
1100
-563
to
563
1080/59.94p, 60p(Level-B)
-2200
to
2200
-563
to
563
2160/23.98PsF, 23.98p, 24PsF, 24p
-1375
to
1375
-563
to
563
2160/25PsF, 25p
-1320
to
1320
-563
to
563
2160/29.97PsF, 29.97p, 30PsF, 30p
-1100
to
1100
-563
to
563
2160/47.95p, 48p(Level-A)
-1375
to
1375
-563
to
563
2160/47.95p, 48p(Level-B)
-2750
to
2750
-563
to
563
2160/50(Level-A)
-1320
to
1320
-563
to
563
2160/50p(Level-B)
-2640
to
2640
-563
to
563
2160/59.94p, 60p(Level-A)
-1100
to
1100
-563
to
563
2160/59.94p, 60p(Level-B)
-2200
to
2200
-563
to
563
