132
11-2-5-3. Dynamic Range Gain
Click Color Processor 1 or Color Processor 2 in the Video Block and select Dynamic
Range Gain to display the window as shown below.
Item
Default
Setting
Description
Simul Mode
Disable
Disable
Enable
Sets whether to keep the gain difference
between FS 1 and 2. Setting to Enable
allows you to set Gain, Color Correction
(Differential, Balance) and Clip (RGB Clip,
YCbCr Clip) parameters by retaining the
gain difference set under Ratio below.
DR Gain
0.00dB
-24.00 to 24.00dB
Sets the RGB dynamic range gain in the
linear scale space.
SDR Gain
0.00dB
0.00 to 24.00dB
Sets the gain difference between SDR and
HDR. The total gain is equal to addition of
SDR Gain and DR Gain values. When
converting between SDR signals or between
HDR signals, this setting is ignored.
Input / Gain / Output / Total
Displays the gain difference between before
and after conversion.
11-2-5-4. Differential Color Correct
Click Color Processor 1 or Color Processor 2 in the Video Block and select Differential
Color Correct to display the window as shown below.
