110
8. Event Memory
Each FA-9600 unit can save and load 10 sets of event memory data.
LOAD EVENT MEMORY
Selects an event number for loading from Event1-100 and Default and press F3 UNITY to load the
event. Before loading events, the Event Load executed!!message appears in the bottom of the
menu.
EVENT
SAVE EVENT MEMORY
Selects an event number for saving from Event1-100 and press F3 UNITY to save settings to the
event number.
While saving data, Event Save executed!” is displayed in the bottom of the front panel screen.
Data cannot be saved to event numbers that are disabled by using the Event Save Limit
function. This function can be enabled only on the Web GUI. See Sec. 13-3-2. “Event Data” for
more details.
EVENT
The [Utility > Event data] page in the Web GUI allows you to change event data name and
content. Refer to Sec. 13-3-2. "Event Data" and Sec. 14. "Event Data (CSV File)" for more details.
START UP EVENT
Selects an event number to be loaded when the unit power turns on.
EVENT
Item
Default
Setting
Description
Start
Last Settings
Last Settings
Loads the settings last used.
Default
Resets all settings to default at startup.
Event 1-100
Loads the selected event memory at startup.
<Items Not Stored by Last Settings>
The following menu settings are not saved by Last Settings and are reset to default whenever
FA-9600 are restarted.
Menu
Item not stored
Sec.
SPLIT MODE SELECT
Mode setting
5-2
AREA MARKER
Marker setting
5-3
TIMECODE GENERATOR LTC/VITC
Start/Stop setting
5-33, 5-34
VIDEO FREEZE
Freeze setting
5-41
VIDEO TEST SIGNAL
Pattern setting
5-44
AUDIO OUTPUT GAIN
Master Mute setting
6-19
ANALOG INPUT/OUTPUT GAIN
Master Mute setting
6-20
