35
5. Video Setting Menus
The MU Main mode (Simultaneous 4K/HD, Dual HD or 3D-LUT) determines which menus can be used
on which FS. The menu access button, available MU Main modes and required option(s) are indicated
on the right side of menu.
See Sec. 1-3. “Three MU MU Main Modes and Sec. 7-8. “MU OPERATION” for more details.
5-1. VIDEO PROCESS AMPLIFIER
Simultaneous 4K/HD
Dual HD
3D-LUT (FS1)
Item
Default
Setting
(Steps)
Description
Control
Select
-
Pre-process
Post-process
Selects a Proc Amp to be set.
Pre-process: Proc Amp before Color Correction
Post-process: Proc Amp after Color Correction
Post-process can be selected only when
FA-96AHDR or FA-96AHDR2 option.
Video Level
100.0 %
0.0 - 200.0 %
Adjusts the video level.
Chroma
Level
100.0 %
0.0 - 200.0 %
Adjusts the chrominance level.
Hue
0.0 deg.
-179.8 - 180.0 deg.
(0.2 deg.)
Adjusts the chroma phase.
Y Level
100.0 %
0.0 - 200.0 %
Adjusts the luminance level.
Setup/Black
Level
0.0 %
-20.0 - 100.0 %
Adjusts the black level.
Keep White
Disable
Disable
Enable
If set to Enable, the Y Level value automatically
changes according to the Black Level setting
(Keep White function).
Always sets to Disable at startup.
