119
Division
(FA-964K)
Follow Input
Follow Input
SQD
2SI
Specifies the SDI image division method. (FS1
only, FA-964K required)
Synchronizer
Format
-
-
Displays the detected video format of SDI
input.
<Dual HD mode>
Item
Default
Setting
Description
Source
Select
IN1 (FS1)
IN2 (FS2)
IN1
IN2
HDMI IN
EX3G IN1 to IN4
SFP RX1 to RX4
Selects a signal input to FS1 or FS2.
EX3G IN1 to EX3G IN4: Require
FA-96EX3G44-R.
SFP RX1 to SFP RX4: Require FA-96SFPC4.
Loss Mode
Back Color
Back Color
Auto Freeze
SDI Output Mute
Selects the output mode for input signal loss.
Back Color: Outputs a monochrome (set under
Back Color below) video.
Auto Freeze: Freezes the last normal output
video.
SDI Output Mute: Outputs no signal so that the
FA-9600 downstream device can detect video
loss.
Back Color
Black
Black, Blue, Red,
Magenta, Green,
Cyan, Yellow
Selects a monochrome used for Loss Mode
settings.
Format
Setting
Auto Detect
Auto Detect
Manual
Specifies the FS output format.
Auto: FS input signal format.
Manual: Signal format specified below.
If Format Setting is set to Manual, specify the format using the following settings.
For supported video formats, see Sec. 16-1. “Specifications.”
Standard
1080
SD
720
1080
Specifies the vertical image resolution.
Horizontal
Size
1920/3840
1920/3840
(Not used)
Frame Rate
59.94i
60p, 59.94p, 50p
48p, 47.95p
30p, 29.97p
25p, 24p, 23.98p
60i, 59.94i, 50i
24PsF, 23.98PsF
30PsF, 29.97PsF
25PsF
Specifies the frame / field rate.
Level
Follow Input
Follow Input
Level-A
Level-B
Specifies the SDI mapping level.
Synchronizer
Format
-
-
Displays the detected input format.
