13
-Redundant power supply system
-GPI input/output card / GPI expansion cable
- LTC input/output expansion cable
(*1)
SD/HD and 3G-SDI if no FA-964K option installed.
(*2)
FA-964K required
(*3)
FA-96UDC required
(*4)
FA-96AHDR (if FA-9600 firmware version is less than 3.0) or
FA-96AHDR2 (if FA-9600 firmware version is 3.0 or higher) required
(*5)
SR-Live for HDR is a high quality and efficient live product workflow provided by SONY
(*6)
FA-96EX3G44-R or FA-96SFPC4 required for Quad Link input.
1-3. Three MU Main Mode
FA-9600 units have two processing systems (FS1 and FS2) and three MU Main mode:
Simultaneous 4K/HD, Dual HD and 3D-LUT. Available functions vary depending on the Mu Main
mode. See Sec. 7-8 “MU OPERATION” and Secs 5-20 to 5-28.
-Simultaneous 4K/HD mode
FS1 supports SD, HD and 4K signals with a full-featured converter.
FS2 supports SD and HD signals with a restricted converter
-Dual HD mode
FS1 supports SD and HD signals with a full-featured converter.
FS2 supports SD and HD signals with a full-featured converter.
- 3D-LUT mode (FA-96AHDR or FA-96AHDR2 required)
FS1 supports SD, HD and 4K signals with a full-featured converter and can convert color space
and dynamic range (between SDR and HDR) using 3D-LUT.
FS2 is disabled.
* Converter function requires FA-96UDC.
* UHD 4K operation requires FA-964K.
* 3D-LUT mode requires FA-9600 Version 3.0 or higher and FA-96AHDR or FA-96AHDR2.
* SR-Live for HDR function requires FA-96AHDR2 optional software.
1-4. Notice on Overheat Protection
◆ If temperature is close to the limit, a warning message is displayed
If FA-9600 internal temperature is close to the upper limit of allowed operating range, a warning
message is displayed on the front panel, Windows GUI and Web GUI. (The message will disappear
if the temperature goes down to normal level.)
◆ If temperature exceeds the limit, FA-9600 stops operation and signal output
If FA-9600 internal temperature exceeds the upper limit of allowed operating range, the FA-9600
stops operation and signal output and displays an alert message that it stops operation due to the
overheat protection, on the front panel, Windows GUI and Web GUI, until it is restarted.
In such cases, power off the FA-9600 and verify that air vents are not obstructed and whether the
environment is causing the overheating. Wait for the device temperature to go down, then turn on
the power.
